When using shims to time your muzzle device it can get frustrating. Fortunately we, as gun owners, have an awesome community of really smart folks. One is KurttheGunsmith. He did all the hard work to figure out how to easily figure out which shims are needed. I took his equation and turned it into a simple calculator.

All of this information is from KurtTheGunsmith, please visit his article on Timing a muzzle device for detailed explanations. He is the man on this one. His Instagram.

Here's the data you'll need!

TPI

You’ll need to know this.

  • If your muzzle device is 1/2×28, your TPI is 28.
  • If your muzzle device is 5/8×24, your TPI is 24.

Get it?

Timing

Think of this like a clock. Where is the top of your muzzle device?

Photo by KurtTheGunsmith

Reminder

**This is based on the Dead Air shim pack sizes. .060″, .006″, .004″.

Shim Calculator for Timing Muzzle Devices.









If you see a bug, report it here.

No guarantees or warranties, the code got complicated quickly.
